     CGM Leading the Industry Trend: Super Crossed Design and Miniature Rollers Boost High-Performance 2-Axis System

In the realm of modern industrial automation, achieving high precision, high load capacity, and compact installation space has always been the relentless pursuit of manufacturers and engineers. CGM (www.linearguider.com) is proud to introduce a groundbreaking 2-axis platform that leads the industry trend, incorporating super crossed design and miniature roller technology to enhance the precision and load capacity of robotic arms while providing outstanding performance within limited installation space.

Super Crossed Design: Achieving High-Precision Positioning CGM's 2-axis platform adopts a super crossed design, merging the X-axis and Z-axis into a highly integrated system. This innovative design not only achieves high precision positioning but also maximizes the repeatability of the robotic arm, reaching an astonishing ±0.04 accuracy. This means that with each movement, the system can accomplish tasks with exceptional precision, ensuring reliability and efficiency in production lines.

Miniature Roller Technology: High-Precision Guidance and Support The X-axis and Z-axis of the 2-axis platform utilize miniature roller technology. This design not only provides high-precision guidance and support but also effectively reduces friction. The precise sliding capability of miniature rollers enables the efficient conversion of the servo motor's rotary motion into linear motion, providing a crucial guarantee for high-speed movement and precise alignment. The application of this technology allows the 2-axis platform to grasp weights of up to 20 kilograms within a radius of 300 millimeters, showcasing remarkable load capacity.

Key Parameter Overview:

• Working Platform: Radius 200 millimeters
• Grip Weight: 20 kilograms
• Maximum Speed: 1500/s
• AC Servo Motor Power: 400 watts
• Repeatability: ±0.04
• Communication Protocol: Supports Ethercat bus communication

Product Highlights:

1. Super Crossed Design: Achieves high-precision positioning for both X-axis and Z-axis, enhancing the overall accuracy of the robotic arm.
2. Miniature Roller Technology: Provides high-precision guidance and support, reduces friction, and efficiently converts the rotary motion of the servo motor into linear motion, ensuring reliability in high-speed movement and precise alignment.

CGM's 2-axis platform, with the combined assistance of super crossed design and miniature roller technology, brings a new realm of possibilities to the industrial automation field. Its high performance and precision will effectively elevate the stability and efficiency of production lines, providing customers with an advanced and reliable solution. For more information about CGM's innovative products, please visit the company website: www.linearguider.com.
