linear motion precision Spindle axes
Explore our precision Spindle axes, expertly designed for converting rotation to linear motion with unparalleled accuracy.
Quantity:
Spindle Axes
Spindle Axes Built-in single-axis systems for dynamic and precise positioning. The single-axis systems have a freely selectable stroke and are delivered with cables, precisely matched drive components, such as servo motors and amplifiers. Thanks to the cooperation with the axle manufacturer, our customers benefit from the combined know-how and receive a high-quality solution from a single source.
| Type | Axis profile | profile width | Drive type | Max.stroke | Max speed | Max.feed force | Repeatability | Max.acceleration (S/㎡) |
| GGk15005 | Aluminium | 150(mm) | Ballscrew | 980,1380,1680,custom-made | 0.5m/s | 3.271（N） | ±0.02 | 15 |
| GGk15010 | Aluminium | 150(mm) | Ballscrew | 980,1380,1680,custom-made | 0.5m/s | 1.93（N） | ±0.02 | 15 |
| GGK15020 | Aluminium | 150(mm) | Ballscrew | 980,1380,1680,custom-made | 1 m/s | 2.541（N） | ±0.02 | 15 |
| GGK20010 | Aluminium | 200(mm) | Ballscrew | 980,1380,1680,custom-made | 0.5m/s | 3.331（N） | ±0.02 | 15 |
| GGK20025 | Aluminium | 200(mm) | Ballscrew | 980,1380,1680,custom-made | 1.25m/s | 1.78（N） | ±0.02 | 15 |
| GGK25010 | Aluminium | 250(mm) | Ballscrew | 980,1380,1680,custom-made | 0.5m/s | 5.3（N） | ±0.02 | 15 |
| GGK25020 | Aluminium | 250(mm) | Ballscrew | 980,1380,1680,custom-made | 1 m/s | 4.069（N） | ±0.02 | 15 |
| GGK25032 | Aluminium | 250(mm) | Ballscrew | 980,1380,1680,custom-made | 1.6 m/s | 2.774（N） | ±0.02 | 15 |
