High-efficiency Air IGBT Electroplating Rectifier with 92% conversion efficiency, MUDBUS RTU protocol, short circuit protection, and durable PVC/steel construction for automated electroplating lines
Quantity:
Product Name: Air IGBT Electroplating Rectifier
Advantages:
- Conversion Efficiency: 92%
- Power Factor: ≥0.9
- MUDBUS RTU communication protocol
- Ripple Factor: ≤1%
- Short circuit protection
- Under/Over voltage protection
- Over temperature protection
- High-quality copper construction
- Strong structure with PVC/steel for durability, attractive appearance, and corrosion resistance
- Low noise, minimal heat generation, and high energy efficiency
- Designed for copper plating, tin plating, nickel plating, and gold plating applications
- Phase lack protection
- Input Over/Low voltage protection
- Operating temperature range: -10°C - 45°C
- Suitable for automatic electroplating lines
Technical Specifications:
- Maximum Output Current: 10,000 Amps
- Maximum Output Voltage: DC 36V
Applications:
- Suitable for various electroplating processes including copper plating, tin plating, nickel plating, and gold plating
- Ideal for use in automated electroplating production lines
Notes:
- Ensure that the operating temperature remains within the range of -10°C to 45°C during use.
- Do not exceed the maximum output current and voltage to avoid impacting the normal operation and lifespan of the equipment.
The above specifications provide basic information about the product. For more detailed technical parameters and specifications, please contact our sales team.
Our company specializes in the professional development and production of electroplating rectifiers using the Modbus RTU protocol, specifically for electroless nickel plating applications
