Three-Phase Input Electroplating Rectifier
0~1500 Amp / DC 0~24.0
High-efficiency electroplating rectifier with adjustable output, precise control, robust protection, and versatile applications in automatic electroplating equipment for various plating processes.
Quantity:
Product Name: Three-Phase Input Electroplating Rectifier
Input Voltage: 400V AC, 3-Phase ±15%
Input Frequency:50/60Hz
Output Voltage: 0~12V (adjustable)
Output Current: 0~1000A (adjustable)
Conversion Efficiency:92%
Power Factor:>0.9
Control Mode: Manual control
Ripple Factor:<1%
Voltage Regulation Precision:≤0.5%
Current Stabilization Precision:≤0.5%
Working Conditions: Indoor only
Environmental Conditions: -10°C to +45°C
Protection Level:IP20
Cooling Type: Air cooling
Protection Features:
- Short circuit protection
- Over/Under voltage protection
- Over-temperature protection
- Phase lack protection
- Input Over/Low voltage protection
Features:
- High-quality copper materials
- Strong structural strength in PVC/steel, attractive appearance, and high corrosion resistance
- Low noise, low heat generation, high energy efficiency
- Suitable for copper plating, tin plating, nickel plating, and gold plating processes
- Working temperature range: -10°C to +45°C
- Suitable for automatic electroplating equipment
For current stabilization during the electroless copper plating PCB process, precise control is essential.
