CGCY Electroplating rectifier

In the electroplating industry, finding a rectifier that is both efficient, easy to install, and features a modular design can be challenging. However, CGCY, with pride, introduces the "Electroplating Rectifier," a product that not only meets these requirements but also excels in performance and reliability.

Product Highlights

1. Easy Installation

The installation process of the CGCY Electroplating Rectifier is straightforward, allowing users to quickly adapt and get it operational. This contributes to higher efficiency and convenience in the electroplating industry.

2. Modular Design

The product adopts a modular design, making maintenance and upgrades easier. This not only reduces maintenance costs but also enhances the product's reliability and stability.

Technical Specifications

• Input Voltage: 400V AC, 3-Phase ±15%
• Input Frequency: 50/60Hz
• Output Voltage: 0~12 V (adjustable)
• Output Current: 0~2000 Amp (adjustable)
• Conversion Efficiency: 92%
• Power Factor: >0.9%
• Control Mode: RS485 Communication
• Ripple Factor: < 3%
• Short Circuit Protection
• Under/Over Voltage Protection
• Over Temperature Protection
• High-Quality Copper Material
• Sturdy PVC/Steel Structure with Attractive Appearance and Strong Corrosion Resistance
• Low Noise, Low Heat, and High Energy Efficiency
• Suitable for Copper Plating, Tin Plating, Nickel Plating, and Gold Plating
• Phase Lack Protection
• Input Over/Low Voltage Protection
• Working Conditions from -10°C to 45°C
• Suitable for Automatic Electroplating Lines

Application Examples

The CGCY Electroplating Rectifier is particularly suitable for PCB electroplating, metal electroplating, and various surface treatment applications. Its high efficiency and reliability make it an ideal choice for automated electroplating lines.

Whether aiming to increase production efficiency, reduce maintenance costs, or seek a reliable, high-performance electroplating rectifier, CGCY's Electroplating Rectifier is the wise choice.

For more information about this product, please visit our official website: www.linearguider.com

We look forward to providing you with an outstanding electroplating solution!
