dimensiones lineales cantilever robot arm

In the rapidly evolving landscape of modern industrial applications, robotic arms have become indispensable tools in automation technology. CGM proudly introduces a groundbreaking product – the GZH178 Cantilever Robot Arm. This product stands out for its exceptional performance and customizable features, offering a wider range of application possibilities for our customers.

GTH17 Series: High Precision, Responsive Cantilever Robot Arm

Innovative Design Concept

In the design of the GTH17 series, we consider the X and Z axes as "dimensiones lineales," cleverly combining them to form the complete cantilever robot arm. This robotic arm can be seen as a highly precise and responsive stage motorized, making it widely applicable across various industrial sectors.

Performance Overview

1. Repeatability: ±0.04mm, providing outstanding motion control precision.

2. Maximum Speed: 2000 (mm/s), facilitating high-speed movements for enhanced production efficiency.

3. Maximum Horizontal Payload: 55KG, Maximum Vertical Payload: 30KG, meeting diverse operational requirements.

4. Rated Thrust: 204 (N), ensuring stability under various working conditions.

5. Stroke Range: 100-3050 mm, providing a larger operational space.

High-Performance Components

The GTH17 series incorporates advanced components to ensure the stability and reliability of the robotic arm:

• AC Servo Motor Output: 750W, delivering powerful support for motion.

• High Rigidity Linear Guide: 20*15.5mm, ensuring stability during movements.

• Sensor: Utilizing the EE-SX672 sensor for real-time environmental sensing, enhancing safety.

Customizable Length, Up to 20 Meters

The unique feature of the GTH17 series lies in its customizable length, catering to the specific needs of customers, with the maximum length reaching up to 20 meters. This provides a broader range of options for special processes and applications in various industries, meeting flexible length requirements.

Conclusion

The introduction of the GZH178 Cantilever Robot Arm signifies CGM's relentless innovation and leadership in the field of robotic arms. With high precision and responsiveness, the GTH17 series comprehensively meets customer demands for robotic arms. Regardless of your industrial application, the GTH17 series is poised to be your efficient partner in achieving automated production.

Feel free to visit our official website www.linearguider.com for more information about the GTH17 series. CGM looks forward to collaborating with you to create a new era of automation.
