GTH6A-000-500-BR Spindle-Axes Mechanical Module

Introduction: The GTH6A-000-500-BR stands as a flagship model in our spindle-axes mechanical module series, garnering widespread acclaim across various industries for its exceptional performance and flexible design. This article provides an in-depth overview of the product's technical specifications, features and advantages, application areas, customer cases, and the manufacturing excellence of our company.

1. Technical Specifications:

• Overall Width: 60mm, Height: 70mm, Length and Stroke customizable based on customer requirements.
• Drive Mode: Ball screw.
• Servo Motor Output: 100W.
• Ball Screw Diameter: 16mm.

2. Carrying Capacity and Speed:

3. Product Advantages:

• Compact installation space, concentrated design height.
• Folding design style for servo motor installation, saving length space.
• Includes functions like origin positioning, front and rear limits, power-off switch.
• Physical buffer adhesive applied to front and rear limits, enhancing safety.

4. Application Areas: The GTH6A-000-500-BR finds extensive applications in areas such as automatic screw installation in mobile phones and automatic focus adjustment in optical system Z-axis.

5. Customer Cases: Our customer OPT, specializing in optical research, extensively utilizes the GTH6A-000-500-BR. Dahuaguangxue employs it for Z-axis positioning in optical systems, achieving automatic focus adjustment.

6. Manufacturing Excellence:

• Parts produced through die-casting, with ample stock (starting from 3000 pieces per part).
• Automated assembly production line ensures product stability and capacity.
• Parts undergo mechanical analysis, corrosion resistance testing, 2D optical analysis, laser correction analysis, tensile testing, thrust testing, and other quality inspection processes.

7. Experience Summary and Continuous Optimization: With eight years of production, our team continually refines and improves the product based on experience and valuable user feedback, ensuring sustained high performance.

8. Conclusion: The GTH6A-000-500-BR attains a prominent market position, earning recognition from engineering design professionals and widespread customer approval. For more information on our spindle-axes series, visit our website: www.linearguider.com.
