hall effect encoder linear axis mechanical module - belt drive

Introduction:

Hello everyone, welcome to the CGM official website! We are thrilled to announce the official launch of our latest product line - the Linear Axis Mechanical Module (Belt Drive), providing you with a more precise and efficient solution for your automation applications.

In this series, our proud keywords include "niple belt," "hall effect encoder," and "CGM Linear Axis Mechanical Module - Belt Drive." These products, known for their outstanding performance and wide applicability in the market, will become an indispensable part of your automation processes.

Product Highlights:

Our GCB22 series is a precision-engineered and easy-to-install mechanical component for linear actuators. We deeply understand the importance of the niple belt, and we have conducted multiple precise calculations on material options, force analysis, and more to ensure excellent performance in various application scenarios.

For the electrical components, we have adopted Hall Effect Encoder counting technology, providing a reliable guarantee for the high precision of our products. Here are some highlights of the product specifications:

• Servo speed (mm): 500, 1000, 1500, 2000, 2500, 3000
• Gear reducer: 1/3
• Max speed (mm/s): 280, 560, 840, 1120, 1400, 1680
• Max load (kg) (horizontal): 95, 95, 95, 85, 65, 60
• Repeatability (mm): ±0.05
• Lead (mm): 100 (if equipped with 1/3 Gear reducer, then lead = 33.33)
• Rated thrust (N): 400
• Range of travel (mm): 100-4500mm/50
• Servo motor output (W): 750W
• Synchronous belt width (mm): 50
• Linear guide SPC (MM): W23*22 (2 SET)
• Sensor: Omron EE-SX674 (NPN)

Application Examples:

Our linear axis mechanical module is widely used in industrial automation, including but not limited to:

• Part arrangement
• Workpiece pressing
• Parts gluing
• Matching pressure
• 3D coating
• Dual-door setting
• Simultaneous dual-side detection
• Screw locking
• SMT device
• Retrieving and placing parts to multiple inspection devices
• Collaborative dispensing
• Collaborative screw locking

Through these practical application examples, our product showcases its outstanding performance and reliability. If you have special requirements, please let us know in advance, and we will provide tailored solutions for you.

Thank you for your attention and support for CGM. We look forward to our Linear Axis Mechanical Module bringing greater convenience and efficiency to your automation production processes. For more details, please visit our official website: www.linearguider.com.
