press fit bushing cantilever robot arm

Hello everyone, welcome to CGM's official blog! We are excited to introduce our latest product – the GZH178 Cantilever Robot Arm, part of the GTH17 series. In this article, we will delve into the key technologies, performance parameters, and the customization advantages this robotic arm offers to our customers.

Overview of the GTH17 Series

The GTH17 series Cantilever Robot Arm is CGM's latest innovative product. Its main features include advanced press fit bushing technology on the X-axis and ball bearing carriages and guide rails technology on the Z-axis, ensuring outstanding performance and reliability under various working conditions.

Technical Highlights

1. Press Fit Bushing Technology

On the X-axis, we have incorporated advanced press fit bushing technology, providing the robotic arm with exceptional positioning accuracy. This technology not only enhances operational efficiency but also extends the lifespan of the robotic arm.

2. Ball Bearing Carriages and Guide Rails Technology

The Z-axis utilizes ball bearing carriages and guide rails technology, ensuring smooth motion and precise control. This allows the robotic arm to achieve highly controllable movements in all directions.

Performance Parameters

• Repeatability: ±0.04mm
• Maximum Speed: 2000mm/s
• Maximum Payload Horizontal: 55KG
• Maximum Payload Vertical: 30KG
• Rated Thrust: 204N
• Stroke Pitch: 100-3050mm

Component Configuration

• AC Servo Motor Output: 750W
• High Rigidity Linear Guide: 20*15.5mm
• Sensor: EE-SX672

Customizable Length Advantage

This cantilever robot arm, composed of gears, racks, and mechanical modules, offers a significant advantage in its customizable length. We can provide custom lengths up to 20 meters, catering to the specific requirements of different industries and applications.

Conclusion

The CGM GZH178 Cantilever Robot Arm stands out with its advanced technology, outstanding performance, and the advantage of customizable length. Whether you are in automation, logistics, or other industries, the GZH178 series is designed to meet your needs for efficient, precise, and reliable robotic arms. For more information or a quote, please visit our official website at www.linearguider.com.

Thank you for your interest in CGM, and we look forward to providing you with excellent automation solutions!
